GUANFENG FOOD MACHINERY

main products include freeze-drying, drying, quick freezing, deep frying, pre-treatment, liquid nitrogen freezing, sterilization, cold chain storage and other food machinery equipment

Spiral Freezer
Spiral Freezer
Spiral Freezer
Spiral Freezer
Spiral Freezer
Spiral Freezer
+
  • Spiral Freezer
  • Spiral Freezer
  • Spiral Freezer
  • Spiral Freezer
  • Spiral Freezer
  • Spiral Freezer

Spiral Freezer

Product Category:

  • Freezing capacity:From 300Kg to 4000Kg/h.
  • Machine design customization can be made to cater specific requirement.
  • The interior of the body is designed to optimize the flow of people for easy cleaning and maintenance.
  • Equipped with CIP cleaning system.And the machine can operate automatically with GUANFENG self-programmed system.
  • Double sided stainless steel polyurethane insulation board is used for the best heat insulation and water resistance.
  • Freezing capacity:From 300Kg to 4000Kg/h.
  • Machine design customization can be made to cater specific requirement.
  • The interior of the body is designed to optimize the flow of people for easy cleaning and maintenance.
  • Equipped with CIP cleaning system.And the machine can operate automatically with GUANFENG self-programmed system.
  • Double sided stainless steel polyurethane insulation board is used for the best heat insulation and water resistance.
  • Product Detail
  • Product advantages
  • 产品概要表格
    • Commodity name: Spiral Freezer

    The spiral freezer produced by GUANFENG Food Machinery is applicable for prepared food, ice cream, pasta, meat and poultry, aquatic products, fried food, small packaged food, etc.<br> Double spiral freezer positions infeed and outfeed at low making it convenient for operation and better matching the production lines of customers. Single spiral with different level of infeed and outfeed.

    The spiral freezer from GUANFENG adopts low-temperature rapid freezing technology, which can reduce the central temperature of food to below -18 ° C in a short time, effectively reduce the formation of ice crystals, and maintain the quality of food. The spiral design makes full use of vertical space, small footprint, and effectively saves factory space. Equipped with an automatic transfer system, continuous operation can be achieved, reducing manual intervention and improving production efficiency.
    If you have specific needs or questions for spiral freezer from GUANFENG, you can provide more information, I can further answer for you!



    Q&A



    How to choose the right model?  Tell me about the capacity and processing materials, we will recommend the suitable machine for you.

    How about the feeding temperature?  +4℃

    How about the discharge center temperature? -18℃



    Component

    Specification

    Structure

    Double spiral; Single spiral

    Drum diameter

    1400-3900mm

    Layers

    7-25

    Insulated enclosure

    Double-sided stainless steel polyurethane insulation board

    Mesh belt width

    370-1050mm

    Infeed length

    2000mm

    Outfeed length

    1000mm

    Control panel

    PLC touch screen, stainless steel electric control cabinet

    Refrigerant

    Freon, Ammonia, CO2 optional

    Evaporator

    Aluminum tube; stainless steel tube/aluminum fin; stainless steel fin

    Defrost

    Water/hot gas/ADF defrosting optional

    Freezing time

    25-125min Stepless variable frequency adjustable

    Cleaning

    Manual/Belt Washer/CIP

    • Freezing capacity:From 300Kg to 4000Kg/h.
    • Machine design customization can be made to cater specific requirement.
    • The interior of the body is designed to optimize the flow of people for easy cleaning and maintenance.
    • Equipped with CIP cleaning system.And the machine can operate automatically with GUANFENG self-programmed system.
    • Double sided stainless steel polyurethane insulation board is used for the best heat insulation and water resistance.

GUANFENG FOOD MACHINERY

Product

Applications

Bakery Products
APPLICATION

Bakery Products

The spiral freezer can freeze the raw bread dough, pizza dough, croissant, baked bread, buns. It can quickly lock the water and nutrition of food, maintain its original taste and flavor.

Seafood Products
APPLICATION

Seafood Products

By gently removing water through freeze - drying, our equipment helps retain the delicate flavor and texture of seafood, making it a great option for seafood processing.

Meat Products
APPLICATION

Meat Products

To remove moisture from meat products, extending their shelf life while maintaining the texture and taste, suitable for a wide range of meat types

Poultry Products(cooked)
APPLICATION

Poultry Products(cooked)

Our spiral freezers are also popular and efficient in freezing the fried chicken nuggets for major fast food chains.

Ready Meals
APPLICATION

Ready Meals

The freeze dryers are capable of preserving complete ready meals, ensuring that the flavors and ingredients remain intact, ready for quick reconstitution

Ice Cream
APPLICATION

Ice Cream

Ice cream needs to be frozen quickly to maintain taste and quality, and spiral freezer can provide a stable low temperature environment to ensure that ice cream is frozen quickly and evenly.
