Vertical Packaging Machine

Product Category:

Vertical Packaging Machine

Model

GZP-180PX

Bag size

Length:50-170(mm)
Width:50-150(mm)

Total power

5.0kw

Power type

220v/50Hz

Noise

≤65db

Air pressure

≥0.6MPa

Weight

400kg

Dimension

1250×840×1200(mm)

Vertical Packaging Machine Feature:

Advanced control system: Using advanced PLC touch screen control, the operation is simpler, and the product packaging and printing date can be completed at one time, saving time and cost.

Optimized design: More convenient disassembly and cleaning; no empty package to avoid waste.

Independent temperature control: horizontal and longitudinal seal temperature independent control, can better adapt to a variety of packaging materials.

Efficient automation: Advanced automatic control system is adopted to improve packaging efficiency and reduce labor costs.

Diversified packaging methods: Support three side sealing, four side sealing, back sealing and other packaging methods to meet the packaging needs of different products.

Accurate filling amount: equipped with accurate measuring device to ensure that the amount of product filling in each bag is accurate, improve product quality and aesthetics.

Vertical Packaging Machine Feature:

Advanced control system: Using advanced PLC touch screen control, the operation is simpler, and the product packaging and printing date can be completed at one time, saving time and cost.

Optimized design: More convenient disassembly and cleaning; no empty package to avoid waste.

Independent temperature control: horizontal and longitudinal seal temperature independent control, can better adapt to a variety of packaging materials.

Efficient automation: Advanced automatic control system is adopted to improve packaging efficiency and reduce labor costs.

Diversified packaging methods: Support three side sealing, four side sealing, back sealing and other packaging methods to meet the packaging needs of different products.

Accurate filling amount: equipped with accurate measuring device to ensure that the amount of product filling in each bag is accurate, improve product quality and aesthetics.

Vertical Packaging Machine

Model

GZP-180PX

Bag size

Length:50-170(mm)
Width:50-150(mm)

Total power

5.0kw

Power type

220v/50Hz

Noise

≤65db

Air pressure

≥0.6MPa

Weight

400kg

Dimension

1250×840×1200(mm)

  • Product Detail
  • Product advantages
  • 产品概要表格
    • Commodity name: Vertical Packaging Machine

    Vertical sealing machine is mainly composed of frame, transmission system, control system, bag making system, filling system, sealing system, finished product output system, etc. The material is automatically transported to the packaging area, and the process of measuring, filling, sealing and cutting is carried out to form a packaging bag. Widely used in food, medicine, chemical, hardware and other industries, especially in the food industry indispensable.

    Vertical Packaging Machine Introduction:

    Vertical sealing machine is mainly composed of frame, transmission system, control system, bag making system, filling system, sealing system, finished product output system, etc. The material is automatically transported to the packaging area, and the process of measuring, filling, sealing and cutting is carried out to form a packaging bag. Widely used in food, medicine, chemical, hardware and other industries, especially in the food industry indispensable.

    Vertical Packaging Machine Application:

    Food Industry Suitable for packaging of puffed food, shrimp, peanuts, popcorn, cereal, melon seeds and other granular, strip, short strip, vermicelli material, and it also can be used for vacuum packaging of liquid, solid, powder paste food, such as: grain, fruit, pickles, preserved fruit and so on. Pharmaceuticals Industry Suitable for vacuum packaging of chemical drugs, medicinal materials, etc.

    Vertical Packaging Machine Parameter:

    Model

    GZP-180PX

    GZP-300D

    GZP-350

    GZP-300E

    Bag size(mm)

    Length 50-170
    Width 50-150

    Length 80-400
    Width 80-300

    Length 100-500
    Width 175-380

    Length 80-180
    Width 80-140
    Height 50-80

    Total power(Kw)

    5.0

    6.0

    5.8

    6.5

    Power type

    220V 50Hz

    380V/220V 50HZ

    380V 50Hz

    AC380V/220V 50HZ

    Noise

    ≤65db

    ≤68db

    ≤75db

    ≤68db

    Air pressure

    ≥0.6MPa

    Weight(Kg)

    400

    1100

    980

    1000

    Dimension(mm)

    1250×840×1200

    1820×1310×1660

    2200x1500x2090

    2052x1228x2051

  • Vertical Packaging Machine Feature:

    Advanced control system: Using advanced PLC touch screen control, the operation is simpler, and the product packaging and printing date can be completed at one time, saving time and cost.

    Optimized design: More convenient disassembly and cleaning; no empty package to avoid waste.

    Independent temperature control: horizontal and longitudinal seal temperature independent control, can better adapt to a variety of packaging materials.

    Efficient automation: Advanced automatic control system is adopted to improve packaging efficiency and reduce labor costs.

    Diversified packaging methods: Support three side sealing, four side sealing, back sealing and other packaging methods to meet the packaging needs of different products.

    Accurate filling amount: equipped with accurate measuring device to ensure that the amount of product filling in each bag is accurate, improve product quality and aesthetics.

  • Vertical Packaging Machine

    Model

    GZP-180PX

    Bag size

    Length:50-170(mm)
    Width:50-150(mm)

    Total power

    5.0kw

    Power type

    220v/50Hz

    Noise

    ≤65db

    Air pressure

    ≥0.6MPa

    Weight

    400kg

    Dimension

    1250×840×1200(mm)

GUANFENG FOOD MACHINERY

Product

Applications

Food Industry
APPLICATION

Food Industry

Suitable for packing of monosodium glutamate, sugar, soup, cereal, seeds, coffee, etc.

Pharmaceuticals Industry
APPLICATION

Pharmaceuticals Industry

Suitable for filling medicine, oral liquid, injection and so on.

Daily Chemical Industry
APPLICATION

Daily Chemical Industry

Suitable for packing of shower gel, shampoo and other daily chemical products.

GUANFENG FOOD MACHINERY

Product

Recommendation

Weighing and distributing machine

Weighing packaging is generally the last process of product processing, weighing and packaging are independent and inseparable.
Weighing and packing plays an important role in ensuring the accuracy of product weight. With the improvement of precision requirements and the increase of labor costs, automatic weighing equipment has gradually become the best choice to replace manual weighing.
Weighing and distributing machine is widely used for quantitative weighing of various materials.

Pillow packaging machine

Pillow packaging machine is a kind of equipment for packaging various kinds of products. The product is placed on the conveyor belt, and as the conveyor belt moves, the packaging material is pulled over and sealed at a specific location by means of heat sealing, etc., thus wrapping the product. Certain parameters can be adjusted according to the size and shape of the product to ensure the suitability of the packaging. It is widely used in the food industry, such as the packaging of cookies, candies, pastries, etc., which can effectively maintain the freshness and hygiene of products. It is also used in the packaging of daily necessities, small industrial parts, etc., which can improve the packaging efficiency.

Multi-row strip packaging machine

Multi-row packaging machine is a kind of machine used for small bag packaging in pharmaceutical, food, daily chemical and other industries.

Filling Machine

Filling machine is mainly used to realize the mechanical filling function of materials, which can fill materials into various containers. Generally divided into: normal pressure filling machine, pressure filling machine, vacuum filling machine, oil filling machine, plug filling machine, paste filling machine, paste filling machine, weighing filling machine. Generally include the following main parts: material storage device, filling device, container conveying device, positioning device, control system.
