Tunnel Quick Freezer

Product Category:

Tunnel Freezer

Efficient quick-freezing: IQF tunnel freezer uses an efficient refrigeration system and optimized airflow design, which can not only reduce the growth of bacteria, but also effectively maintain the nutritional content and taste of food
Continuous production: The IQF tunnel freezer adopts continuous conveyor belt design, which can achieve continuous and uninterrupted freezing treatment of food.
Precise control of speed and time: It's possible to adjust the conveyor belt speed and the time the goods spend in the tunnel.

Efficient quick-freezing: IQF tunnel freezer uses an efficient refrigeration system and optimized airflow design, which can not only reduce the growth of bacteria, but also effectively maintain the nutritional content and taste of food
Continuous production: The IQF tunnel freezer adopts continuous conveyor belt design, which can achieve continuous and uninterrupted freezing treatment of food.
Precise control of speed and time: It's possible to adjust the conveyor belt speed and the time the goods spend in the tunnel.

Product Detail
Product advantages
产品概要表格

Commodity name: Tunnel Quick Freezer

The tunnel quick freezer can freeze or chill all kinds of products according to your needs including slice fruit, vegetables in tray, seafood, meats, prepared dishes, hanging meat carried on racks, etc. This tunnel freezer is designed for industrial purposes that can deep-freeze large-volume products in a minimum amount of time.

What is the operating principle of Dessert Tunnel Freezer?

According to different varieties prodcuts to be frozen, put in the trays or directly on the conveying belt, rapidly frozen by the wind blowing from the top to the bottom or by the side wind.

Efficient quick-freezing: The tunnel freezing machine uses an efficient refrigeration system and optimized airflow design, which can quickly reduce the temperature of food and achieve rapid freezing. This can not only reduce the growth of bacteria, but also effectively maintain the nutritional content and taste of food.
Energy saving and environmental protection: The tunnel IQF freezer adopts advanced energy-saving technology, such as frequency conversion control, heat recovery, etc., which can reduce energy consumption and operating costs. At the same time, the optimized refrigeration system and air flow design also reduce the consumption and emissions of refrigerants, in line with environmental requirements.
High space utilization: Tunnel designs usually have a small footprint and are suitable for mass production.

Model Parameters	GSD-100	GSD-200	GSD-300	GSD-500	GSD-1000
Capacity（kg/h）	100	200	300	500	1000
Overall dimensions(m)	8.52.32.48	9.52.82.48	12.02.82.48	14.73.32.48	20.73.82.48
Length of freezing room(m)	6.0	7.0	9.5	12.2	18.2
Inlet material temperature(℃)	+15
Outlet material temperature(℃)	-18
Freezing temperature(℃)	≤-33
Freezing time（min）	6-60（variable frequency regulation）
Refrigerant	R22/R404A/R717
Cold Consumption（kw）	22	35	55	95	165
Installation Power（kw）	6.8	7.1	10.5	19.8	31.0

- Efficient quick-freezing: IQF tunnel freezer uses an efficient refrigeration system and optimized airflow design, which can not only reduce the growth of bacteria, but also effectively maintain the nutritional content and taste of food
- Continuous production: The IQF tunnel freezer adopts continuous conveyor belt design, which can achieve continuous and uninterrupted freezing treatment of food.
- Precise control of speed and time: It's possible to adjust the conveyor belt speed and the time the goods spend in the tunnel.

Hot Tags:

GUANFENG FOOD MACHINERY

Mesh Belt Tunnel Freezer

Tunnel Quick-Freezing Machine

GUANFENG FOOD MACHINERY

Product

Applications

APPLICATION

Variety Fruits & Vegetables

GUANFENG freeze dryers can preserve the natural color, flavor, and nutritional value of various fruits and vegetables, making them convenient for long - term storage and rehydration.

APPLICATION

Meat Products

To remove moisture from meat products, extending their shelf life while maintaining the texture and taste, suitable for a wide range of meat types

APPLICATION

Seafood

Tunnel quick freezer is perfect for freezing seafood, such as shrimp, fish, and scallops. The low temperature and high-speed airflow quickly freeze the seafood, locking in its freshness and natural flavors. This extends the shelf life and maintains the quality of the seafood.

APPLICATION

Bakery Products

The spiral freezer can freeze the raw bread dough, pizza dough, croissant, baked bread, buns. It can quickly lock the water and nutrition of food, maintain its original taste and flavor.

APPLICATION

Dairy Products

GUANFENG tunnel freezer is suitable for dairy products, such as ice cream, yogurt, and cheese. The controlled environment ensures that the dairy products are quickly frozen without damaging their texture or flavor. This extends their shelf life and maintains their quality.
