Ice Water Pre-cooling Machine
Product Category:
|
Ice Water Pre-cooling Machine |
|
|
Model |
GBL460 |
|
Output (T/h) |
1.0t/h |
|
Size |
5880*1600*1200mm |
|
Belt width |
600mm |
|
Water consumption |
0.3~0.5t/h |
|
Cold consumption |
50kw |
|
install power |
3.3kw |
|
Customizable |
OEM |
Ice Water Pre-cooling Machine Features:
-
Feeding form: frequency control
-
Equipped with ice water cooling coil tank and circulating device ice water heating.
-
Electrical control: The electrical components adopt from CHNT, and the transmission frequency converter adopt Delta from Taiwan.
-
Material: Made of SUS304 stainless steel except for standard parts, such as motor, electric appliance.
Ice Water Pre-cooling Machine Features:
-
Feeding form: frequency control
-
Equipped with ice water cooling coil tank and circulating device ice water heating.
-
Electrical control: The electrical components adopt from CHNT, and the transmission frequency converter adopt Delta from Taiwan.
-
Material: Made of SUS304 stainless steel except for standard parts, such as motor, electric appliance.
|
Ice Water Pre-cooling Machine |
|
|
Model |
GBL460 |
|
Output (T/h) |
1.0t/h |
|
Size |
5880*1600*1200mm |
|
Belt width |
600mm |
|
Water consumption |
0.3~0.5t/h |
|
Cold consumption |
50kw |
|
install power |
3.3kw |
|
Customizable |
OEM |
- Product Detail
- Product advantages
- 产品概要表格
-
- Commodity name: Ice Water Pre-cooling Machine
The Ice water pre-cooling machine is to cool the fruits and vegetables after blanching by ice water, so that the central temperature of the material is reduced to about 15℃.<br> GUANFENG provides customization for normal temperature pre-cooling and ice water pre-cooling machine with different capacities.
Ice Water Pre-cooling Machine Introduction：
The Ice Water Pre-cooling Machine is a highly efficient and advanced solution designed to cool fruits and vegetables after blanching by using ice water. This process reduces the central temperature of the materials to around 15℃, ensuring optimal preservation of texture, color, and nutritional value. With its automation, food-grade stainless steel construction, and customizable design, the Ice Water Pre-cooling Machine is the best choice for modern food processing needs.
Ice Water Pre-cooling Machine detailed：
The Ice water pre-cooling machine is to cool the fruits and vegetables after blanching by ice water, so that the central temperature of the material is reduced to about 15℃.
Ice Water Pre-cooling Machine Parameter:
Model
GBL-4-60
GBL-5-70
GBL-5-80
GBL-6-90
GBL-6-100
Dimensions (mm)
5880*1600*1200
7100*1825*1200
7100*2420*1200
8320*2595*1200
9540*2770*1200
Capacity(T/h)
1.0
2.0
3.0
4.0
5.0
belt width(mm)
600
700
800
900
1000
Water consumption(T/h)
0.3~0.5
0.6~1.0
0.9~1.5
1.2~2
1.5~2.5
Cold consumption(kw)
50
100
145
195
245
Installation Power(kw)
3.3
3.7
3.7
5.2
6.2
-
Ice Water Pre-cooling Machine Features:
-
Feeding form: frequency control
-
Equipped with ice water cooling coil tank and circulating device ice water heating.
-
Electrical control: The electrical components adopt from CHNT, and the transmission frequency converter adopt Delta from Taiwan.
-
Material: Made of SUS304 stainless steel except for standard parts, such as motor, electric appliance.
-
-
Ice Water Pre-cooling Machine
Model
GBL460
Output (T/h)
1.0t/h
Size
5880*1600*1200mm
Belt width
600mm
Water consumption
0.3~0.5t/h
Cold consumption
50kw
install power
3.3kw
Customizable
OEM
GUANFENG FOOD MACHINERY
Product
Applications
Variety Fruits
According to the processing needs, the fruit can be pre-treated such as cleaning and cutting to improve the subsequent processing efficiency and product quality.
Variety Vegetables
The quality and safety of vegetable products can be ensured through scientific pre-treatment processing, and also could improve the processing efficiency and economic benefits.
